AF Modular Submersible Micropump System



AF MODULAR SUBMERSIBLE MICROPUMP SYSTEM is a ultra-light, really portable system allows pumping, sampling and developing piezometers and monitoring 2" F or larger wells with water level down to 35 m from ground surface.



TECHNOLOGY:

Modular elements, each one comprehending submersible pump unit, electric cables, waterproof connectors, flexible pipe and quick hydraulic joints. Each element gives a total dynamic head up to 10 m needing a 5 A, 12 Volts DC. It's possible to assemble up to 4 elements in series in order to reach a total dynamic head of 40 m.



AF MODULAR SUBMERSIBLE MICROPUMP SYSTEM comprehends:

  • pumping system

  • energizers

PUMPING SYSTEM:


Each modular elements is constituted by a submersible pump, 10 m long PEHD pipe, quick hydraulic joint, submersion proof electric wire and connectors. Pump maximum outer diameter is 41 mm, maximum discharging rate 17l/min (4 Imp. Gal / min). Total weight for single element is 1.2 Kg

ENERGIZER

  • Lead, sealed, maintenance free power pack with built in AC 220 Volts recharger, 7 A/h capacity. Charge level built in indicators , carry belts. (total weight 6,5 Kg).

  • Ultra-light 1% oil gasoline mix powered, low emission AC-DC generator (particularly suitable for long time jobs). Generator is even particularly suited for long, maintenance free storage.
